JBL Stage3 527F Car Speaker

JBL Stage3 527F – 5.25-inch Car Speakers (2-Way Coaxial)

The JBL Stage3 Series combines patented technologies and superior engineering to deliver powerful performance with excellent compatibility for dealer installations. It features a 3-ohm design (2Ω high DCR) to extract more power from the recorder/amplifier, a Plus One™ polypropylene cone for a larger vibration surface and better bass, a vented basket for voice coil cooling, JBL's signature consistent sonic tuning, and OEM-level reliability testing standards.

Features

• High output design thanks to 2Ω DCR to extract every available watt.
• Plus One™ cone for increased effective area and improved bass and efficiency.
• Engineered to Fit for best fit to factory mounting locations.
• Vented Basket for better cooling, higher power capacity and less distortion at high volume.
• Rigorous reliability testing and audio calibration to maintain the well-known JBL signature .

Technical specifications

Size and Type5.25 in (130 mm), 2-way (no grille)Nominal Power (RMS)40 watts per speakerPeak Power (Peak)120 watts per speakerSensitivity (@2.83V/1m)91 dBFrequency Range75 Hz – 20 kHzNominal Impedance3 ohms

Dimensions (according to the engineering drawing)

• Outer diameter: 129.9 mm
• Mounting hole (Cutout): 113.6 mm
• Top-mount depth: 54.0 mm
• Approximate total depth: 58.9 mm

Box Contents

• 2 x Earphones

Official documents from JBL/Harman

• Official Specifications (Spec Sheet)
• Owner's / Installation Manual
